ASME design by analysis for nozzles, supports, and heads, before fabrication
Send your drawings and loads. Get a roadmap to a vessel that passes.
Design-by-rule formulas cover simple shells and heads. Nozzles, supports, lugs, and local loads often don't fit them. Pressure vessel stress analysis uses FEA to check those details. It applies the design-by-analysis rules of the ASME Boiler and Pressure Vessel Code.
When the analysis is skipped, teams do one of two things. They add wall thickness and reinforcement until the hand checks pass, and pay for the steel on every vessel. Or they find the problem at review, at hydrotest, or in service. There, every fix costs weeks.
As pressure vessel design consultants, PPS works alongside our FEA consulting services and FEA thermal analysis services. Our ASME Section VIII Division 2 analysis services show where the stress really is and what the code allows. You get a vessel with the wall it needs, documented for your reviewer.
✓
A nozzle load stress problem the tables don't cover
Piping loads and local stresses need a real model.
✓
Thick walls set by conservative hand checks
Extra steel on every vessel you build.
✓
Supports, saddles, or lugs on thin shells
Local loads can govern before the shell does.
✓
Cyclic pressure or temperature in service
Fatigue life decides how long the vessel lasts.
✓
A reviewer asking for design by analysis
Division 2 methods need documented stress results.
✓
A rerate, repair, or change in service
The original calculations no longer cover the duty.
Cost you carry
Decision it lets you make
Result
Unit cost
Material & weight
Decision
Find the real stress at nozzles, heads, and supports, then size the wall to what the code allows.
→
Result
Thinner sections where the code allows, with margin kept.
Development
Prototypes & testing
Decision
Check the design against code limits before fabrication, and go to hydrotest to confirm.
→
Result
Fewer surprises at review and at hydrotest.
Tooling
Rework & redesign
Decision
Find the overstressed nozzle or support in simulation and fix it before plate is cut.
→
Result
No rework after fabrication; the vessel is built once.
After launch
Field failures & warranty
Decision
Screen pressure cycles and thermal stress in pressure vessel walls for fatigue, and release with margins you can document.
→
Result
Longer service life and a design you can defend in review.
01
A design that meets your loads at the lowest total cost, delivered as production-ready CAD and drawings
02
FEA results and margins you review and approve at each gate, before anything moves to prototyping.
03
You own the IP by default, set in your contract.
04
If we missed it in our QC, we fix it. If your supplier can't make the part within three years, or supply dries up, we fix that too.
You send
What we need to start
CAD, native or STEP
Loads and operating conditions, or how the part is used
Material specs or test data, if you have it
Targets: weight, cost, life, or code
Failure history, if a part already failed
→
You get
What you hold at the end
The optimized design: CAD and drawings ready for production
Models and results you reviewed and approved
Documented margins or code compliance
Test correlation, when testing is in scope: a partner lab or yours
A roadmap for what comes next, and a team that stays with you
We price to the value we deliver, not the hours we log. If the value isn't there for you, we'll say so in the assessment.
Pressure Vessel · Industrial Client
Before
Wall thickness set by conservative linear checks. Extra material on every vessel.
After
Elastic-plastic analysis to ASME BPVC Section VIII, Division 2 proved the real collapse margin.
15%
Thinner wall
Div 2
Design by analysis
0
Code margin lost
We review your project scope and the drawings, design conditions, and history you have, and screen which details govern.
Scope, targets, and gates, from where you are to where you need to be.
Design-by-analysis FEA with CAD changes, plus testing when the design needs it.
The design, drawings, and models, second-checked in our QMS.
We stand behind the design through production and supply issues.
PPS engineers run FEA, CFD, and DFMA as one loop. FEA checks the code limits, and CFD sets thermal loads where flow matters. CAD changes follow, and fabrication cost is checked before plate is cut. The vessel you approve is the vessel that ships.
Formulas for shells and heads
Or add thickness until it does
Plate cut and welded
A nozzle or support is overstressed
New pads, new plate, new hydrotest
Which details govern the design
Stresses checked to code limits
Geometry refined to real margins
Second engineer verifies the model
Build once, to confirm
Every review loop you fund is margin lost. Get a free roadmap.
Get Your Free RoadmapReactors, jacketed tanks, and receivers checked at nozzles and supports so they pass review the first time.
Pass review first time.
Applications
Jacketed Tanks
Reactors
Nozzles
Supports
Vacuum and pressure cycling on large doors and chambers screened for buckling, fatigue, and seal loads.
Built for every cycle.
Applications
Vacuum
Doors
Fatigue
Seals
Drums, heaters, and separators checked for pressure, thermal transients, and nozzle loads in service.
Fewer forced outages.
Applications
Transients
Heaters
Nozzles
Fatigue
External pressure and collapse checked for housings and hull penetrations before they go into service.
Pass class review first.
Applications
Collapse
Housings
Penetrations
Class Rules
FEA, CFD, CAD, DFMA, and testing under one roof. Engineering is a team sport, and you get the whole team.
One team, every skill.
Under One Roof
FEA
CFD
CAD
DFMA
Testing
Veteran-owned SDVOSB status gives defense and federal buyers a set-aside path to proven engineering.
Verify our SDVOSB status.
Credentials
SDVOSB
VOSB
CAGE 8ZK73
NAICS 541330
Missed something in our QC? We fix it. Supplier can't make the part within three years? We fix that too.
Support for the long run.
We Fix
Our QC Misses
Supplier Gaps
Supply Chain
We price to the value we deliver, not hours logged. You buy a design that works, not more iterations.
Pay for the result only.
Collections
Gold
Platinum
Diamond
When does a vessel need pressure vessel stress analysis by FEA?
A vessel needs pressure vessel stress analysis by FEA when the code's design-by-rule formulas no longer describe the part. Those formulas sit in the ASME Boiler and Pressure Vessel Code. They work for plain shells and heads. They say little about large nozzles or lugs on thin shells. Watch for five signs. Nozzle or piping loads exceed what the tables cover. Supports, saddles, or lugs sit on a thin shell. The vessel sees cyclic pressure or temperature. A reviewer or customer asks for design by analysis. Or the walls are thick because nobody could prove a thinner one. Each sign means the hand checks guess or overbuild.
Design by analysis lets the model show the real stress and compare it with the code limits. PPS reviews your project scope in a free assessment and tells you which details need analysis. Many vessels need it at only one or two nozzles, and the rest can stay on rules. Where yielding or collapse governs, our nonlinear analysis FEA takes the check further.
Do you work to Division 1 or Division 2?
Our pressure vessel stress analysis supports both. Most vessels are designed to Section VIII, Division 1 rules. Division 1 allows analysis where its formulas don't cover a detail, such as a large nozzle, a lug, or a local load. Each of those details needs a documented stress check. Division 2 adds full design-by-analysis methods: elastic stress analysis, elastic-plastic analysis for collapse, buckling checks, and fatigue screening. It also uses different allowable stresses, so the same vessel can often come out lighter. Pick the wrong route and you either overbuild the vessel or redo the analysis late, when a reviewer asks for more.
You or your fabricator choose the code route with your Authorized Inspector, and we model to the ASME codes and standards you name. Your reviewer gets clear plots, linearized stress results, and a summary of each load case, in a form they can follow. For thermal transients, our FEA thermal analysis services supply the temperatures. The certified fabricator applies the code mark; we give them the analysis behind it.
What do you need from us to start?
To start a project with our pressure vessel stress analysis, send what you have, in any format. That usually means drawings or CAD, native or STEP, and the design pressures, temperatures, and nozzle loads. Add material specs, the code edition and division, your cost targets, and any inspection history. Missing data is a common reason engineering projects stall. A model built on guessed inputs gives a guessed answer, and a guessed answer can fail a review. That is why we don't start the work until every data set is in. For gaps in material data, NIST's Material Measurement Laboratory is a good first stop.
Once your data is in, the first step is a free assessment of your project scope. We confirm what the work can and can't answer, and tell you what is still missing. Then we send a roadmap proposal with scope, targets, and approval gates. Every project is scoped on its own, so the roadmap sets the schedule, not a stock promise. NDAs are available before you share any files.
Who owns the design and the models?
You own the IP from your pressure vessel stress analysis project by default, as set in your contract. That covers the design, the drawings, and the models. Some firms keep the models or license them back to you, so every later change sends you back to them, at their price. That locks your vessel to one vendor. It also makes reviews and rerates harder, because your team can't open the evidence behind the decisions. Your inspector may ask for that evidence too. Export-controlled programs add another layer. The State Department's ITAR portal sets the rules for defense data, and a loose handoff can break them.
At PPS, nothing is held back to tie you to us. You receive the native CAD, the drawings, the model files, and the documented results. Your engineers can check the work, rerun a load case, or hand the package to a fabricator. We sign mutual NDAs before any data is shared. Tell us about export rules at the start, and we set up data handling to match.
What happens if a vessel fails review or hydrotest?
If a vessel fails review or hydrotest, we find out why and fix the design. With pressure vessel stress analysis from PPS, you approve the data at each gate. So a test result is checked against predictions you have already seen, not against a black box you can't open. Hard engineering carries unknowns. Real loads, material lots, and weld details never match a model perfectly. A failure in test is data, because it shows which assumption was wrong. That data improves the model and the design. NASA's standard for models and simulations sets out how to judge whether a model's results can be trusted.
When testing is in scope, our design validation services plan the test to confirm the margins that matter most. Then we correlate the model to the results. If the miss was ours, because something slipped through our QC review, we fix it. If the test finds a condition nobody knew about, we scope the change with you and update the roadmap. Either way, you get a clear answer.
How is pressure vessel stress analysis priced?
We price every pressure vessel stress analysis project to the value it delivers, not the hours we log. Hourly billing rewards extra iterations. The meter keeps running whether or not the design improves. So the cheapest quote can become the most expensive project once rework shows up. Federal buyers know this risk well. The Federal Acquisition Regulation notes that a time-and-materials contract gives the contractor no positive profit incentive for cost control or labor efficiency. Our incentive runs the other way: get the design right the first time. We engage by fit, not as a ladder, so you start where your need is.
Gold (from $35K): you have one project and need help with it. Platinum (from $15K/mo): you have recurring work at a steady rhythm. Diamond (from $800K/yr): you have a long development program, often multi-year. Gold is never required, and these are starting points, not quotes. We price to the value we deliver, not the hours we log. If the value isn't there for you, we'll say so in the assessment.
Rules not enough? Send your drawings. Get a free roadmap now.
Send your drawings and loads. We review your project scope in a free assessment and reply within one business day with next steps.
On-site assessments that require travel are quoted separately.
